All the advantages of the Flex Strips extended up to 20 m long. The PROLED Flex Strip Xtend RGBW is perfect when you have large rooms and long walls to illuminate with continuous light quality.
- Excellent light quality and colour rendering, and – thanks to 48-volt technology – uniform dimming over the entire length
- Perfect for halls, corridors and long walls
- Suitable as ambient lighting, orientation and accent lighting
- Only one power feed needed for a length of 20 m
- Significantly reduced installation effort
- Dimmable with suitable PWM dimmers
TECHNICAL DATA
IP20
Power source 48 VDC
Electrical connection 2x cable to open wires
5-pin
30 cm
Maximum quantity per power input 20 m
Average lifetime 50.000 h at L80/B10
Operating temperature range -10° C till +45° C
Width x height 14 x 2 mm
min. Bending radius 20 mm
Cuttable all 13 LEDs (16,7 cm)
PHOTOMETRIC DATA
LED type SMD RGBW 4-in-1 LEDs
Luminous flux
red 120 Lumen per m
green 300 Lumen per m
blue 70 Lumen per m
white 350 Lumen per m
r+g+b+w 840 Lumen per m
Wave length
red 620 nm
green 525 nm
blue 470 nm
Colour temperature
neutral white 4000 K
super warm white 2700 K
CRI80
Beam angle 120°
