Insert+ 2

Series of wall recessed luminaires for indoor and outdoor general lighting use in two sizes, comprising: Polyester powder-painted die-cast aluminium housing Powder polyester painting process optimized against UV rays in 13 different steps Diffuser in flat glass, internally frosted EPDM gasket Stainless steel locking screws Supplied with 0,2 m pre-wired HORNF-5 cable External electrical connection with sealed plug-socket QUICK, complete with cable Electrical connector for wires Ø 7 - Ø 12 mm For the Insert+2 series,connectors for through wiring connections are available as accessories. Connectors fit wires measuring Ø 7 - Ø 10.5 mm and Ø 14 - Ø 17 mm The fixture requires recessed fixing box which must be ordered separately The recessed box is equipped with a removable cover and provided with two spirit levels to facilitate the installation process INSERT+ 1/2 could be installed in exisitng recess boxes of INSERT 1/2 thanks to the dedicated adapter accessory LED versions include 220/240 V 50/60 Hz safety transformer
