Light up orbit

Light Up Orbit - body in stainless steel • Floor/ground-, wall- and ceilingmounted recessed luminaires (except ø 80 mm) intended for use with LED light sources. • Possibility of installation on the ground without frame casing. • Comprises body and frame casing. • Body and frame in AISI 304 stainless steel installed without visible screws, hardened safety glass A2 stainless steel cable gland complete with outgoing power supply cable of 2x1 mm² type. The cable is provided with IP68 antitranspiration device. • Polypropylene plastic frame casing to be ordered separately • Optics with plastic lenses or reflectors. • Safe low voltage power supply at constant current (350/500/700mA depending on the type of specifi c recessed luminaires) to be ordered separately. • Static load resistance 2000 Kg using frame casing to be ordered separately. • Roll-over product in accordance with EN 60598-2-13 (torsion strength and shear load tests). • Installation is not permitted in areas where snow ploughs are used at driving speed of over 50 km/h. • Compact dimensions of the luminaire (<100mm). • IP68 protection for product and cable alike using IP68 connectors. The product is not considered suitable for installation in swimming pools and fountains.
