Overall dimensions
Information
A series of motorized roller blinds specifically designed for outdoor installations on building facades. Possibility of side-to-side mounting for continuous facades, transforming the blinds into an essential part of the building's architecture.A choice of elegant shades, with round headbox, stainless steel cables or bars, or with aluminum side channels, inclusive of characteristic support brackets. Installation: OutdoorsBrackets: custom AISI 304 stainless steel brackets to support the guide rods, for face or ceiling/floor mounting on request Headbox: extruded aluminum suspended CT110 round box. AISI 316 stainless steel flanges (satin finish) composed of two parts that clamp onto the bar guides and hence support the whole blind. The box is hence suspended on the guide rods and not fixed to the buildingRoller tube: Ø 60 mm extruded aluminum tube or Ø 78 mm galvanized steel tube, both with slot to facilitate fabric removalSide channels: AISI 316 stainless steel Ø10mm guide rods Bottom rail: round FD42 extruded aluminum bottom rail with galvanized steel weight and Delrin end caps that slide along the guide rods Colour: white powder coated RAL 9010, silver anodizedOperation: Motorized, M50 tubular motor with top/bottom limit switches and mains cable, thermal cut-out and class IP44 water resistance.
