Information
XLINE Strip is a design aluminium profile equipped with Philips LED strip and acrylic cover, ensuring a powerful and uniform light distribution and a unique stylish atmosphere.
TECHNICAL DATA
IP20
Power source 220-240 VAC 50/60 Hz
Housing powder coated aluminium white (RAL 9003) or black (RAL 9005), cover white opal
Driver including (700 mA)
Electrical connection 5-PIN terminalblock
Average lifetime 40.000 h at L80/B10
Operating temperature range -10° C till +45° C
Dimmable dimmable DALI
PHOTOMETRIC DATA
LED type PHILIPS LUXEON 3020
Luminous flux warm white 3200 Lumen
Colour temperature warm white 3000 K
CRI80
Beam angle 110°
