Vector frame a 9819

VECTOR FRAME A 9819 is a LED recessed powder coated aluminium lamp for false ceiling. Mountings: Built-in installation, In false ceiling - plasterboard Light emission: Direct, Symmetric Body In extruded aluminium, painted with SOLVENT-FREE, white or black, epoxy polyester powders, thermosetting at 180°C, after phosphate treatment Wiring plate Removable wiring plate in extruded aluminum painted with white-colored epoxy polyester powders, thermosetting at 180°C, with surface phosphating pretreatment Header In printed aluminum interlocking Optical device Microprismatic polycarbonate diffuser Light source: LED CRI ≥ 80 / 90 3000K 4000K Color tolerance: 3 - MacAdam (3 SDCM) Lifetime: 80000 hours - L80B20 Wiring: Class I Power supply 220 ~ 240 V / 50-60 Hz Performance: • Efficiency A+ • Degree of protection: IP20 • UGR ≤ 19 Marks: CE Regulations: EN 60598-1 EN 60598-2-1 EN 62031 Photobiological safety of lamps and lamp system: EN 62471 IEC/TR 62778 Exempt risk - GR 0 Directives: 2014/35/UE 2014/30/UE VERSIONS ON REQUEST • DALI dimmable electronic ballast • Emergency complex 1h
