Information
Recessed for outdoor applications (not suitable for use in swimming pools or fountains)
recessed (floor)
2W
24Vdc
Lumen output at source: 96 lm (3000K)
Delivered lumen output: 70 lm (3000K)
side-emitting LEDs
LED colour: 2700K, 3000K, 4000K, Blue
Optics: radial
body in anodized aluminium, trim in AISI 316L stainless steel, screen in PMMA
power supply unit not included
includes 1.5 m neoprene cable, H05RN-F 2x0,35/0,75 Ø6.3 mm
Ingress protection: IP68
Impact resistance: IK10
anti-vandal kit available on request
Protection systems: IPS
Operating temperature: -20°C — +45°C
Maximum device temperature: 45°C (Ta 25°C)
Glow wire test: 960°
Photobiological safety: risk group 1 according to EN6 2471:2006
Appliance class: III
Weight: 400 g
Dimensions: Ø78x41 mm
Accessories: WC0100 Outer casing, WC0103 Outer casing, WC0150 Outer casing, WF8405 Neoprene cable - 5 m H05RN-F 2x0,35/0,75 Ø6,3 mm - IPS, WF8410 Neoprene cable - 10 m H05RN-F 2x0,35/0,75 Ø6,3 mm - IPS, WF8415 Neoprene cable - 15 m H05RN-F 2x0,35/0,75 Ø6,3 mm - IPS, WF8420 Neoprene cable - 20 m H05RN-F 2x0,35/0,75 Ø6,3 mm - IPS
Energy efficiency class: A / A+ / A++
