Information
Recessed for outdoor applications (not suitable for immersion in swimming pools or fountains)
drive-over up to 2000 kg
recessed (ceiling, wall, ground)
body in AISI 316L stainless steel or black anodized aluminium, trim in AISI 316L stainless steel or aluminium, screen in tempered, transparent extra-clear glass, screen in extra-clear tempered, sandblasted glass (diffuse optics)
finishes: stainless steel, grey
1 power LED High Intensity
RGB: 3 power LEDs
5W, 7W - 24Vdc
RGB: max 5W - max 500mA
includes 1,5 m neoprene cable, H05RN-F 2x0,75/0,75 Ø6,3 mm
RGB: includes 1,5 m FEP+PCP cable (equivalent to H05RN-F cable) 6x0,50/0,50 Ø6,3 mm
delivered lumen output: 352 lm (3000K, 34°, 5W, CRI 80), 284 lm (3000K, 34°, 5W, CRI 90), 463 lm (3000K, 34°, 7W, CRI 80), 374 lm (3000K, 34°, 7W, CRI 90), RGB: 191 lm (R: 70 lm, G: 90 lm, B: 31 lm)
optics: asymmetrical 8°, 8°, 11°, 17°, 21° sharp, 34°, 45°, 47°, 61° sharp, 68°, 13°x52°, diffuse
RGB: 20°, 34°, 45°, 21°x42°
LED colour: white - 2700K, 3000K, 4000K
RGB
ingress protection: IP68, IP69K
impact resistance: IK10
equipped with IPS and PID
operating temperature: -20°C+45°C
screen temperature: max 40°C (Ta 25°C)
Glow Wire Test: 960°
photobiological safety: risk group 1 in accordance with EN62471:2006
appliance class: III
weight 0,33 kg (aluminium trim) 0,44 kg (stainless steel trim)
body dimensions Ø85x63 mm
cut-out size Ø70 mm
overall volume Ø180x120 mm
dimming using a dimmable power supply unit
accessories: outer casing WC0100, outer casing WC0103, fixing springs WG0100, honeycomb louvre WH0201, semi-diffusing screen, half transparent and half frosted WE0400A, anti-glare screen, half transparent and half serigraphed black WE0400S
